BreezIntegrity - ITG50HLED - 50 CFM Fan/Dimmable LED Light with Humidity Sensor-- Discontinued
Replacement Model GBR80HLED

Home / Products / BreezIntegrity / ITG50HLED

ITG LED
  • ITG50HLED
  • ITG50HLED Grille
  • ITG50HLED indicator
  • ITG50H LED indicator
  • ITG50HLED
  • ITG50HLED
  • ITG50HLED
Integrity
  • ENERGY STAR® qualified with brushless DC motor technology
  • Quiet operation at 0.7 sones
  • Ceiling mount ventilating fan/Dimmable LED Light rated for continuous running
    • Included:
    • 13-watt LED light included (equivalent to a 60-watt incandescent bulb)
    • Dimmable LED light (dimmable switch not included)
    • Main light output: 850 Lumens; 3000K; 90 CRI for high color accuracy and compliance with CEC JA8 Title 24 requirements
  • Energy efficiency at 12.5 CFM/Watt
  • Adjustable humidity set points between ~50% to ~80% RH
  • LED life is 30,000 hours (compare with 10,000 hours CFL life)
  • Self-compensating motor speed for intended airflow when static pressure is encountered
  • Annual energy cost for 24/7 operation is approximately $5.26*
  • *Calculations based upon U.S. average retail electricity and HVI testing labs. Actual results may vary

  • energyefficient logo
  • LED Dimmable logo
  • CA24 logo
  • ASI logo

The Builder’s Choice for Green Construction.
Delta BreezIntegrity ITG50HLED has been awarded ENERGY STAR® Most Efficient 2018 with brushless DC motor engineered to run continuously for a minimum 70,000 hours. Airflow rating of 50 CFM and loudness rating of 0.7 Sones at 0.1 static pressure as certified by the Home Ventilating Institute (HVI); power consumption of 5.0 Watts with efficiency rating of 11.0 CFM/Watt at 0.1” static pressure; motor lock protection and self-compensating motor speed for intended airflow when static pressure is encountered. UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.

ITG50HLED - 50 CFM Fan/LED Dimmable Light

Static Pressure (inches w.g.) 0.1 0.25
Air Flow (CFM) 50 38
Sones 0.7 1.3
Power Consumption (Watts) 5.0 7.0
Energy Efficiency (CFM/Watts) 12.5 6.7
Current (Amps) 0.22 Max
Power Rating (V/Hz) 120/60
LED Light (Watt) 13.0

Digital Files for Revit Users
For the convenience of the Architectural and Engineering professionals who rely on quality BIM content to deliver their projects, Delta Breez offers powerful functionality in our easy to use Revit Families (.rfa’s). Download them today for free.

Families Include:
• Accurately Modeled Geometry
• Revit Electrical Connector
• Revit Duct Connector
• Type Catalogs Files (.txt) for small file size.
• Face-Hosted for Easy Placement.

Download Revit File
